Axelera Metis M.2 AI Edge Accelerator – High Performance for Computer Vision
The Axelera Metis M.2 AI Edge Accelerator Card is a compact and highly efficient AI accelerator for demanding computer vision applications . With up to 214 TOPS (INT8) of computing power in the M.2-2280 M-Key form factor , the card enables the parallel processing of numerous image and video streams – with a typical power consumption of only 4–8 W.
The specially developed Metis AI Processing Unit (AIPU) is optimized for high performance and low power consumption. It is ideal for Industry 4.0, robotics, logistics, security systems, and medical technology . Thanks to its industrial-grade temperature range (-40 to +85 °C) and long-term availability , the module is the perfect choice for long-life B2B applications in the edge sector.
Highlights:
-
Up to 214 TOPS INT8 computing power
-
Energy efficient: only 4–8 W power consumption
-
Industrial temperature range (-40 to +85 °C)
-
Compact M.2-2280 M-Key form factor
-
Optimized for Edge AI & Computer Vision
Product variants
The Axelera Metis M.2 AI Edge Accelerator Card is available in two versions:
-
With passive heatsink:
Suitable for systems without additional airflow. Heat is reliably dissipated via the heatsink, ensuring stable performance even under continuous load. -
Without heatsink:
Ideal for embedded or OEM solutions that already incorporate their own cooling strategy (e.g., case fans, heat pipes, or active cooling modules). This variant saves height and enables more flexible integration into compact systems.
Both variants are based on the same Metis AIPU architecture and offer up to 214 TOPS (INT8) performance. The choice depends primarily on thermal requirements and the planned installation environment.
Technical data
| feature | specification |
|---|---|
| Model number | AXE-BME20M1AB01A01 |
| architecture | Quad-Core Metis AIPU |
| performance | Up to 214 TOPS (INT8) |
| Form factor | M.2 2280 M-Key |
| interface | PCIe Gen 3, 4 lanes (4 GB/s bidirectional) |
| On-board memory | 1 GB DRAM |
| Operating temperature | -40 to +85 °C |
| Power consumption | 4–8 W typical |
| Security features | Secure Boot, Root of Trust |
| compatibility | ARM & x86 systems, Linux & Windows |
Software support (inferencing)
For software integration, Axelera provides the Voyager SDK , allowing developers to quickly and efficiently deploy deep learning models on the Metis AIPU.
Features:
-
Runs deep neural networks with high energy efficiency
-
Especially optimized for CNNs and computer vision applications
-
Supports parallel processing of multiple models and streams
-
Runs on Linux and Windows
-
Compatible with ARM and x86 systems
Framework & model support:
-
PyTorch and ONNX natively supported
-
TensorFlow via ONNX
-
Automatic quantization (FP32 → INT8) and graph optimization for maximum performance and accuracy
Example models from the model zoo:
-
Image Classification: ResNet-50, MobileNetv2
-
Object Detection: MobileNetv2-SSD, YOLOv5, YOLOv6, YOLOv7, YOLOv8, YOLOv9
-
Segmentation: DeepLabv3, YOLOv8-seg, U-Net
-
Pose Estimation: YOLOv8-pose
Areas of application
-
Industry 4.0 & Automation
-
Security and surveillance systems
-
Robotics & Autonomous Systems
-
Smart Mobility & Logistics
-
Medical image processing
-
Agritech & Smart Farming
Advice from buyzero
We can advise you on whether your model is compatible with the Axelera AI Metis chip and whether you can implement your project using Axelera AI. Please contact us.
