BESCHREIBUNG
Entwirf deinen eigenen Pi HAT, füge eigene Schaltkreise hinzu und kleide deinen Pi Zero, A+, B+, Pi 2, Pi 3 und Pi 4 (jeden Pi mit einem 2x20-Anschluss) mit diesem flotten Prototyping HAT-Kit ein.
Zum Auftakt der Adafruit HAT-Party haben wir dieses von Perma-Proto inspirierte Plug-in-Tochterboard. Es hat ein Raster von 0,1" Prototyping-Lötlöchern zum Anbringen von Chips, Widerständen, LEDs, Potentiometern und mehr. Die Löcher sind unten mit Leiterbahnen verbunden, um die lötfreien Breadboards zu imitieren, mit denen Sie vertraut sind. Es gibt auch lange Steckdosenleisten für +3V, +5V und Masseanschlüsse an den Pi. Oben sind fast alle Pins aufgeführt, die man mit dem Pi verbinden kann (#26 hat es nicht ganz geschafft).
Es wird mit einer Leiterplatte und einem einzelnen 2x20 GPIO Header für den Raspberry Pi geliefert, um den Perma-Proto auf den Raspberry Pi zu setzen (wie einen netten kleinen Hut...) Diese Version wird nicht mit einem EEPROM geliefert, so dass man ihn mit anderen HATs "stapeln" kann, ohne sich um eine EEPROM-Adressenkollision zu sorgen.
Sie können Ihr Perma-Proto-Setup mit einem standardmäßigen 2x20-Stacking-Header oder einem extra hohen 2x20-Stacking-Header anpassen. Sie können den 2x20 Header auch gegen einen schlanken 2x20 Typ austauschen, wenn er näher am Pi sitzen soll, oder einen extra hohen, wenn er über den USB/Ethernet-Ports sitzen soll.
Um den Header auf der Platine zu befestigen, muss man ein wenig löten, aber es ist eine leichte Arbeit.
Dieser Hut ist nur mit dem Raspberry Pi Zero/A+/B+/2/3/4 (jeder Pi mit 2x20-Anschluss) kompatibel! Er funktioniert nicht mit dem Raspberry Pi Model A oder B mit 2x13-Anschluss.
TECHNISCHE DETAILS
- Abmessungen des Headers: 5mm x 51mm x 12mm / 0.2" x 2" x 0.5"
- PCB-Abmessungen: 66mm x 57mm x 2mm / 2.6" x 2.2" x 0.1"
DESCRIPTION
Design your own Pi HAT, attach custom circuitry and otherwise dress your Pi Zero, A+, B+, Pi 2, Pi 3 and Pi 4 (any Pi with a 2x20 connector) with this jaunty prototyping HAT kit.
To kick off the Adafruit HAT party, we have this Perma-Proto inspired plug in daughter board. It has a grid of 0.1" prototyping soldering holes for attaching chips, resistors, LED, potentiometers and more. The holes are connected underneath with traces to mimic the solderless breadboards with which you're familiar. There's also long power strips for +3V, +5V and Ground connections to the Pi. Near the top we break out nearly every pin you could want to connect to the Pi (#26 didn't quite make the cut).
It comes with a printed circuit board and a single 2x20 GPIO Header for Raspberry Pi to put your Perma-Proto on top of your Raspberry Pi (like a nice little hat...) This version does not come with an EEPROM so you can 'stack' it with other HATs without worrying about an EEPROM address collision.
You can customize your Perma-Proto setup using a standard 2x20 stacking header or extra tall 2x20 stacking header. You can also swap out the 2x20 header with a slim 2x20 type if you want it to sit closer to the Pi, or an extra tall one if you want it to sit above the USB/Ethernet ports.
A bit of light soldering is required to attach the header to the PCB but it's easy work.
This hat is only compatible with the Raspberry Pi Zero/A+/B+/2/3/4 (any Pi with 2x20 connector)! It will not work with the Raspberry Pi Model A or B with 2x13 connector.
TECHNICAL DETAILS
- Header Dimensions: 5mm x 51mm x 12mm / 0.2" x 2" x 0.5"
- PCB Dimensions: 66mm x 57mm x 2mm / 2.6" x 2.2" x 0.1"
