ED-HMI3120-101CC – 10.1" Industrial HMI with CM5, camera & 4G

The EDATEC ED-HMI3120-101CC is a modern, high-performance 10.1-inch industrial HMI based on the Raspberry Pi Compute Module 5 (CM5) . With its capacitive multi-touch TFT display, robust metal housing, and flexible power supply voltages, it is ideally suited for demanding automation, control, and IoT applications – such as machine control, plant monitoring, or smart factory environments.

The panel offers high performance and flexibility: RAM and flash memory can be selected as needed, and it features integrated dual LAN interfaces, four isolated RS232/RS485 ports, USB, HDMI, and Micro-SD and M.2 SSD expansion options. WiFi/Bluetooth , a 4G LTE module , and a front-facing camera are available as options – making the 101CC particularly well-suited for mobile applications, remote data transmission, or remote monitoring.

Additionally, a supercapacitor module (UPS backup) can be integrated, making the device resilient even in unstable power supply environments – a clear advantage for industrial settings. Thanks to its modular configurability and diverse interfaces, the ED-HMI3120-101CC provides a flexible, scalable solution for Industry 4.0, embedded projects, or gateway applications.

Product variants

The ED-HMI3120-070C series offers several configurable versions for various industrial applications:

• ED-HMI3120-070C

• ED-HMI3120-101CC – Version with optional front camera

• • RAM options: 2 GB / 4 GB / 8 GB / 16 GB LPDDR4

  • eMMC options: 16 GB / 32 GB / 64 GB

  • Optional: WiFi & Bluetooth , 4G/LTE module , supercapacitor module (UPS)

Note: All variants can be supplied on request and are individually configurable for your application.

Technical data

Individual configuration (Ordering Code) - Your custom-made ED-HMI3120-101C

The EDATEC Ordering Code enables flexible, project-specific configuration of the ED-HMI3120-101C. Customers can tailor the device precisely to their industrial requirements.

• RAM: 2 GB / 4 GB / 8 GB / 16 GB

• eMMC storage: 16 GB / 32 GB / 64 GB

• Camera option: Marking “C” for models with camera (e.g. “101CC”)

• Wireless: Device optionally with or without WiFi & Bluetooth

• 4G/LTE: Codes like "4EU" stand for versions with an integrated mobile communication module.

• Supercapacitor module (optional):

  • Short-term emergency power supply

  • Protection against voltage dips

  • Protection against data loss

  • Ideal for industrial environments with potentially unstable power supplies

• Accessories: Power supplies, mounting kits, cables, expansion modules, etc.

We configure each variant individually – perfect for industrial applications that require maximum reliability and flexibility.

Scope of delivery

• 1× ED-HMI3120-101CC

• 1× mounting kit (panel mount / VESA)

• 1× Quick Start Guide

• Optional accessories depending on configuration

• Power supply not included (can be ordered separately)

Areas of application

Ideal for industrial, B2B and embedded applications:

• Machine control & automation

• Process visualization & SCADA systems

• Building Automation & Smart Building

• IoT gateways with 4G communication

• Data acquisition, remote maintenance & monitoring

• Mobile control units, embedded terminals

Notes

• Camera, WiFi/Bluetooth, 4G, Supercapacitor are optional modules
• All variants of the 101C series are available upon request.
• Power supply not included.
